(JIC)JMV-44/22 NEW/JMV-53/34(6-8T TRAVEL MOTOR)/JMV-147/95
1 – VALVE PLATE – 1
2 – FRICTION PLATE – 3
3 – SEPERATION PLATE – 3
4 – CYLINDER BLOCK – 1
5 – BALL GUIDESPRING – 6
6 – BALL GUIDE WASHER – 1
7 – BALL GUIDE – 1
8 – RETAINER PLATE – 1
9 – PISTON SHOE – 9
10 – SWASH PLATE – 1
11 – SERVO BALL – 2
12 – DRIVE SHAFT – 1
All original manufacturer’s names, part numbers and description are for reference purposes only and it does not imply that any Part listed is the product of these manufacturers
