Hand Pumps, Hydraulic Inline Valves
PRB Series Single Acting Hand Pumps
Working volume: 12, 18, 25 and 45 cc
Max. pressure: Up to 320 bar
Pressure relief valve and dust protection cover options
From 1 liter up to 10 liter steel oil tank options
Hydraulic hand pumps provide hydraulic energy for many industrial applications working pressure up to 320 bar. They are compact and perfect choice if your system need hydraulic pressure.
|
Code |
Working volume |
Rated pressure |
Function |
Oil tank assembly |
|
PRB12 |
12 |
320 |
Double acting function for single acting cylinder |
Rectangular steel tank |
|
PRB25 |
25 |
250 |
Double acting function for single acting cylinder |
Rectangular steel tank |
|
PRB45 |
45 |
160 |
Double acting function for single acting cylinder |
Rectangular steel tank |
|
PRP12 |
12 |
300 |
Single acting function for single acting cylinder |
Round steel tank |
|
PRP15 |
15 |
250 |
Single acting function for single acting cylinder |
Round steel tank |
|
PRP18 |
18 |
200 |
Single acting function for single acting cylinder |
Round steel tank |
|
PRP25 |
25 |
160 |
Single acting function for single acting cylinder |
Round steel tank |
|
PRBC20 |
20 |
250 |
Double acting function for single acting cylinder |
– (Fixing to wall) |
|
* Hand pumps are supplied with levers |
||||
All original manufacturer’s names, part numbers and description are for reference purposes only and it does not imply that any Part listed is the product of these manufacturers
