(KOBELCO/KATO)HD3000
1 – VALVE PLATE MOTOR – 1
2 – BEARING PLATE – 1
3 – DRUM SEAL – 7
4 – SPRING SEAT – 7
5 – BACK-UP RING – 7
6 – SNAP RING – 7
7 – CYLINDER BLOCK – 1
8 – RETAINER – 1
9 – RETAINER PLATE – 1
10 – PISTON SHOE – 7
11 – THRUST PLATE – 1
12 – SWASH PLATE – 1
13 – SADDLE BEARING – 2
14 – DRIVE SHAFT – 1
All original manufacturer’s names, part numbers and description are for reference purposes only and it does not imply that any Part listed is the product of these manufacturers
