Directional Control Valves, Selector Valves
DVS6 Series Selector Valves
Nominal flow rate: 50 liter/min
Max. Pressure: 315 bar, without drain line 210 bar
Voltage: 12 or 24 V DC
Fluid temperature range: -10 oC … +80 oC
Working fluid: Mineral based hydraulic oil
Viscosity: 10-100 cSt (46 cSt mineral based hydraulic oil is recommended, may vary in different climates)
Filtration: 9 to NAS 1638
Directional control valves are one of the core elements in a hydraulic circuit. They help directing the fluid to different components in the system.
Directional control valves perform only three functions:
There is a part called «spool» inside control valve which can be operated mechanically or electrically. The movement of the spool lets oil flow or blocks the oil flow in other words it controls the movement of fluid. Hidros provide monoblock directional control valves with different capacities and spool control options such as hydraulic, pneumatic or with cables/joysticks.
DVS valves are 6 ways, 2 positions (6/2) solenoid operated valves. They are used for selective connection of different cylinders/hydraulic motors in the application. When valve is de-energised, oil directs from D & C ports to first actuator. When valve coil is energised, oil directs from A & B ports to second actuator.
Code |
Port size |
Nominal flow rate |
Max. pressure with drain line |
Voltage |
DVS6-L-12DC-G12-02 |
G 1/2” |
50 |
315 |
12 |
DVS6-L-12DC-G38-02 |
G 3/8” |
50 |
315 |
12 |
DVS6-L-24DC-G12-02 |
G 1/2” |
50 |
315 |
24 |
DVS6-L-24DC-G38-02 |
G 3/8” |
50 |
315 |
24 |
All original manufacturer’s names, part numbers and description are for reference purposes only and it does not imply that any Part listed is the product of these manufacturers
