Directional Control Valves, Forest Crane Valves

8ZC70 Series Solenoid Operated Forest Crane Valves (With anti-shock valves)

Nominal flow rate: 70 liter/min
Max. Pressure: P: 250 bar, T: 50 bar, A-B: 300 bar
Spool type: Standard open center spool (A spool), different spool and spool control options
Number of spools: 8
Leakage: 6 cm³/min at 100 bar (From A,B to T)
Voltage: 12 V DC
Fluid temperature range: -20 ^oC … +80 ^oC
Working fluid: Mineral based hydraulic oil
Viscosity: 10-100 cSt (46 cSt mineral based hydraulic oil is recommended, may vary in different climates)

DESCRIPTION
Directional control valves are one of the core elements in a hydraulic circuit. They help directing the fluid to different components in the system.

Directional control valves perform only three functions:

1.   Stop fluid flow
2.   Allow fluid flow
3.   Change direction of fluid flow

There is a part called «spool» inside control valve which can be operated mechanically or electrically. The movement of the spool lets oil flow or blocks the oil flow in other words it controls the movement of fluid. Hidros provide special directional control valves for forest crane applications. This model is with solenoid operated sections and joystick controls. Anti-shock valves are included with the sections.
